CRANKCASE COVER LEFT

CRANKCASE PARTS LEFT FOR ROYAL ENFIELD HIMALAYAN 410 EURO 4

CRANKCASE PARTS RIGHT

(1) 574111/A

HEX FLANGE NUT - M12 X 1.25P X 11(W ), MAGNETO

(10) 574033/C

PLUG M14 X 12, OIL DRAIN

(11) 144846/A

COPPER WASHER

(12) 574030/D

COVER, STRAINER

(13) 574031/A

O-RING, OIL STRAINER COVER

(14) 574029/A

STRAINER COMP. ENGINE OIL

(15) 574019/C

HEX FLANGE BOLT M8 X 12, OIL GALLERY

(16) 574020/A

GASKET W ASHER - 8.2 X 16 X 1, OIL GALLERY BOLT

(17) 574018/B

HEX SOCKET HEAD SCREW M6 X 12

(18) 574016/B

JET COMP, STARTER CLUTCH OIL

(19) 574017/A

O-RING - 4 X 1.2, OIL JET

(2) 574110/A

KEY W OODRUFF

(20) 574015/B

JET COMP, PISTON OIL

(21) 574005/A

BEARING - 6204, CRANK BALANCER

(22) 574008/A

BEARING (#6203LU),COUNTER SHAFT,LH

(23) 574036/D

STUD M6 X 37, CYLINDER BARREL

(24) 574035/B

HOLLOW DOWEL (OD13X18), COVER-RH

(25) 574007/A

BEARING (#6305LU), DRIVE SHAFT LH

(26) 574011/B

OIL SEAL, DRIVE SHAFT

(27) 574264/A

O-RING, SPACER ENGINE SPROCKET

(28) 574263/B

SPACER, ENGINE SPROCKET

(29) 574265/D

FD SPROCKET COMP

(3) 574108/B

HEX SOC HEAD CAP SCREW - M6X1X 20

(30) 574266/B

TAB WASHER M20, ENGINE SPROCKET LOCK

(31) 574267/C

NUT M20, ENGINE SPROCKET

(32) 574012/A

RETAINER, DRIVE SHAFT OIL SEAL

(33) 574013/A

BOLT M6 X 10, DRIVE SHAFT OIL SEAL RETAINER

(34) 574320/C

SPROCKET COVER

(35) 574319/C

FLANGED HEXOGANAL BOLT M6X1 X 35

(36) 574367/B

HEX FLANGE BOLT - M8 X 100

(37) 574037/A

HEX FLANGE BOLT- M8 X 70

(38) 574504/C

HEX FLANGE BOLT – M6 X 60

(39) 574038/B

HEX FLANGE BOLT - M6 X 85

(4) 574190/B

FLANGED HEXOGANAL BOLT M6X1 X 16

(5) 574024/H

GEAR POSITION SENSOR

(6) 574026/B

PIN, GEAR POSITION

(7) 574027/B

SPRING, GEAR POSITION PIN

(8) 572371/A

OIL SEAL

(9) 574032/C

HEX FLANGE BOLT-M6 X 21

(A1) 574601/A

FLYWHEEL MAGNETO ASSY (EFI) - VARROC

(A1) 574604/A

MAGNETO ASSEMBLY (DUCATI)

(A2) 888474

STARTER CLUTCH ASSEMBLY

(A3) 888460

OIL STRAINER KIT

(A4) 888461

DRAIN PLUG WASHERS KIT

(A5) 888462

CRANKCASE FASTENERS KIT

(A6) 888463

CRANKCASE LH OIL SEAL & O-RING KIT

	Part number	Description	Qty
# A1	574601/A	FLYWHEEL MAGNETO ASSY (EFI) - VARROC	£334,38
# A2	888474	STARTER CLUTCH ASSEMBLY	£202,20
# A3	888460	OIL STRAINER KIT	£15,76
# A4	888461	DRAIN PLUG WASHERS KIT	£1,84
# A5	888462	CRANKCASE FASTENERS KIT	£12,18
# A6	888463	CRANKCASE LH OIL SEAL & O-RING KIT	£11,16
# A1	574604/A	MAGNETO ASSEMBLY (DUCATI)	Contact	£0,00
# 1	574111/A	HEX FLANGE NUT - M12 X 1.25P X 11(W ), MAGNETO	£1,00
# 2	574110/A	KEY W OODRUFF	£1,20
# 3	574108/B	HEX SOC HEAD CAP SCREW - M6X1X 20	£0,49
# 4	574190/B	FLANGED HEXOGANAL BOLT M6X1 X 16	£0,55
# 5	574024/H	GEAR POSITION SENSOR	£44,57
# 6	574026/B	PIN, GEAR POSITION	£1,26
# 7	574027/B	SPRING, GEAR POSITION PIN	£0,35
# 8	572371/A	OIL SEAL	£2,69
# 9	574032/C	HEX FLANGE BOLT-M6 X 21	£0,74
# 10	574033/C	PLUG M14 X 12, OIL DRAIN	£2,62
# 11	144846/A	COPPER WASHER	£1,10
# 12	574030/D	COVER, STRAINER	£7,00
# 13	574031/A	O-RING, OIL STRAINER COVER	£5,29
# 14	574029/A	STRAINER COMP. ENGINE OIL	£7,01
# 15	574019/C	HEX FLANGE BOLT M8 X 12, OIL GALLERY	£0,70
# 16	574020/A	GASKET W ASHER - 8.2 X 16 X 1, OIL GALLERY BOLT	£0,42
# 17	574018/B	HEX SOCKET HEAD SCREW M6 X 12	£1,26
# 18	574016/B	JET COMP, STARTER CLUTCH OIL	Contact	£0,00
# 19	574017/A	O-RING - 4 X 1.2, OIL JET	£0,50
# 20	574015/B	JET COMP, PISTON OIL	Contact	£0,00
# 21	574005/A	BEARING - 6204, CRANK BALANCER	£11,47
# 22	574008/A	BEARING (#6203LU), COUNTER SHAFT, LH	£9,17
# 23	574036/D	STUD M6 X 37, CYLINDER BARREL	£1,10
# 24	574035/B	HOLLOW DOWEL (OD13X18), COVER-RH	£0,97
# 25	574007/A	BEARING (#6305LU), DRIVE SHAFT LH	£28,00
# 26	574011/B	OIL SEAL, DRIVE SHAFT	£4,88
# 27	574264/A	O-RING, SPACER ENGINE SPROCKET	£2,77
# 28	574263/B	SPACER, ENGINE SPROCKET	£7,81
# 29	574265/D	FD SPROCKET COMP	£19,90
# 30	574266/B	TAB WASHER M20, ENGINE SPROCKET LOCK	£0,53
# 31	574267/C	NUT M20, ENGINE SPROCKET	£3,67
# 32	574012/A	RETAINER, DRIVE SHAFT OIL SEAL	£2,09
# 33	574013/A	BOLT M6 X 10, DRIVE SHAFT OIL SEAL RETAINER	£0,31
# 34	574320/C	SPROCKET COVER	£32,52
# 35	574319/C	FLANGED HEXOGANAL BOLT M6X1 X 35	£1,26
# 36	574367/B	HEX FLANGE BOLT - M8 X 100	£1,81
# 37	574037/A	HEX FLANGE BOLT- M8 X 70	£1,39
# 38	574504/C	HEX FLANGE BOLT – M6 X 60	£1,10
# 39	574038/B	HEX FLANGE BOLT - M6 X 85	£0,86

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Royal Enfield. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKCASE PARTS LEFT of your Royal Enfield HIMALAYAN 410 EURO 4 of HIMALAYAN. Let us know if you have any questions.
