Parts diagram

GEARBOX

FUEL INJECTION AND SENSORS FOR ROYAL ENFIELD HIMALAYAN 410 EURO 4

OIL COOLER

(1) 574140/G

CYLINDER HEAD

(10) 593090/C

NUT M6 X 1, FLANGE NYLOC TYPE

(11) 571208/D

THROTTLE BODY ASSY

(12) 571086

INJECTOR

(13) 571090/A

SEAL RING, INJECTOR

(14) 571087/A

O-RING

(15) 573935/A

SPACER

(16) 571088/C

CAP, INJECTOR ASSEMBLY

(17) 571249/A

STUD-INJECTOR

(18) 500712/B

CLIP HOSE - ADAPTOR

(19) 1020035/A

O-RING TERMPERATURE SENSOR

(2) 574161/A

ENGINE TEMPERATURE SENSOR WITH ORING

(20) 571226/A

VALVE, BY-ST

(21) 571227/A

SPG.,COMPR - VALVE,BY-ST

(22) 571228/A

HOLDER CABLE - VALVE,BY-ST

(23) 571229/A

GUIDE CABLE - VALVE,BY-ST

(24) 571230/A

CAP - VALVE,BY-ST

(3) 521200/A

O RING

(4) 576140/A

INSU LATOR

(5) 574503/B

O-RING FOR MANIFOLD

(6) 576141/A

MANIFOLD - INLET

(7) 571206/A

SS HEX SOCKET HEAD CAP SCREW (M6X25)

(8) 144636/A

WASHER

(9) 571091/A

ADAPTOR WITH PAV CONNECTOR - DIA 32MM

(A1) 571086

INJECTOR KIT ASSEMBLY

(A2) 888192

ADAPTOR WITH PAV CONNECTOR & O-RING KIT

(A3) 570472

SUB ASSEMBLY MANIFOLD INLET KIT

	Part number	Description	Qty
# A1	571086	INJECTOR KIT ASSEMBLY	£88,46
# A2	888192	ADAPTOR WITH PAV CONNECTOR & O-RING KIT	£36,18
# A3	570472	SUB ASSEMBLY MANIFOLD INLET KIT	Contact	£0,00
# 1	574140/G	CYLINDER HEAD	Contact	£0,00
# 2	574161/A	ENGINE TEMPERATURE SENSOR WITH ORING	£34,25
# 3	521200/A	O RING	£3,85
# 4	576140/A	INSU LATOR	£2,30
# 5	574503/B	O-RING FOR MANIFOLD	Contact	£0,00
# 6	576141/A	MANIFOLD - INLET	£25,15
# 7	571206/A	SS HEX SOCKET HEAD CAP SCREW (M6X25)	£1,04
# 8	144636/A	WASHER	Contact	£0,00
# 9	571091/A	ADAPTOR WITH PAV CONNECTOR - DIA 32MM	£22,96
# 10	550086/A 593090/C	NUT M6 X 1, FLANGE NYLOC TYPE	£0,82
# 11	571208/D	THROTTLE BODY ASSY	£402,26
# 12	571053/A 571086	INJECTOR	£88,46
# 13	571090/A	SEAL RING, INJECTOR	£8,86
# 14	571087/A	O-RING	£10,04
# 15	571110/B 573935/A	SPACER	£7,70
# 16	571088/C	CAP, INJECTOR ASSEMBLY	£32,44
# 17	571249/A	STUD-INJECTOR	£3,50
# 18	500712/B	CLIP HOSE - ADAPTOR	£3,50
# 19	1020035/A	O-RING TERMPERATURE SENSOR	Contact	£0,00
# 20	571226/A	VALVE, BY-ST	£16,84
# 21	571227/A	SPG., COMPR - VALVE, BY-ST	£9,64
# 22	571228/A	HOLDER CABLE - VALVE, BY-ST	£10,13
# 23	571229/A	GUIDE CABLE - VALVE, BY-ST	£18,30
# 24	571230/A	CAP - VALVE, BY-ST	£11,44

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Royal Enfield. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FUEL INJECTION AND SENSORS of your Royal Enfield HIMALAYAN 410 EURO 4 of HIMALAYAN. Let us know if you have any questions.
