REAR SWING ARM AND BEARINGS FOR ROYAL ENFIELD HIMALAYAN 410 EURO 4

FRONT WHEEL

(1) 866195

SWING ARM WITH BEARING-ASSY

(10) 587516/B

W ASHER-CHAIN PAD

(11) 594046/A

HEX SOCKET BUTTON HEAD M6X1 SCREW

(12) RLX00155/A

PHILIPS PAN HEAD SCREW M6X6

(13) 594817/A

CLIP-REAR DISC HOSE

(14) 587803/C

CHAIN GUARD

(15) 594216/B

CHAIN TENSIONER COMP-LH

(16) 587708/B

PLATE - CHAIN ADJUSTER

(17) 586005/A

FLANGED HEX NUT M8

(18) 591577/D

FLANGED HEX BOLT M6X1X27

(19) 587818/D

CHAIN – GUIDE

(2) 587515/C

SPINDLE - SWING ARM

(20) 147617/B

HEXAGON FLANGE BOLT, M6X1X14

(21) 1017009/A

SPACER CHAIN GUARD

(3) 585645/B

END CAP RH - SWING ARM

(4) 585751/A

OIL (DUST) SEAL - SWING ARM

(5) 587526/C

INNER RACE -NEEDLE BEARING

(6) 587531/C

INNER SPACER - SWING ARM

(7) 587598/C

SPACER - SWING ARM

(8) 593024/D

HEX NYLOCK NUT M12

(9) 587855/B

REAR CHAIN-PAD

(A1) 587855/B

CHAIN PAD KIT

(A2) 888482

CHAIN TENSIONER KIT

	Part number	Description	Qty
# A1	888481 587855/B	CHAIN PAD KIT	Unit Price Incl. Tax £10,91
# A2	888482	CHAIN TENSIONER KIT	Unit Price Incl. Tax £25,58
# 1	866195	SWING ARM WITH BEARING-ASSY	Unit Price Incl. Tax £141,08
# 2	587515/C	SPINDLE - SWING ARM	Unit Price Incl. Tax £41,16
# 3	585645/B	END CAP RH - SWING ARM	Unit Price Incl. Tax £7,94
# 4	585751/A	OIL (DUST) SEAL - SWING ARM	Unit Price Incl. Tax £3,26
# 5	587526/B 587526/C	INNER RACE -NEEDLE BEARING	Unit Price Incl. Tax £31,07
# 6	587531/C	INNER SPACER - SWING ARM	Not available	£0,00
# 7	587598/C	SPACER - SWING ARM	Unit Price Incl. Tax £5,76
# 8	593024/D	HEX NYLOCK NUT M12	Unit Price Incl. Tax £1,64
# 9	587855/B	REAR CHAIN-PAD	Unit Price Incl. Tax £10,91
# 10	587516/B	W ASHER-CHAIN PAD	Unit Price Incl. Tax £0,90
# 11	594046/A	HEX SOCKET BUTTON HEAD M6X1 SCREW	Unit Price Incl. Tax £1,04
# 12	147896/C RLX00155/A	PHILIPS PAN HEAD SCREW M6X6	Unit Price Incl. Tax £1,48
# 13	594817/A	CLIP-REAR DISC HOSE	Unit Price Incl. Tax £0,54
# 14	587803/B 587803/C	CHAIN GUARD	Unit Price Incl. Tax £11,08
# 15	594216/B	CHAIN TENSIONER COMP-LH	Unit Price Incl. Tax £15,28
# 16	587708/B	PLATE - CHAIN ADJUSTER	Unit Price Incl. Tax £3,26
# 17	586005/A	FLANGED HEX NUT M8	Unit Price Incl. Tax £1,21
# 18	591577/C	FLANGED HEX BOLT M6X1X27	Not available	£0,00
# 19	587818/D	CHAIN – GUIDE	Unit Price Incl. Tax £5,69
# 20	147617/A 147617/B	HEXAGON FLANGE BOLT, M6X1X14	Unit Price Incl. Tax £0,25
# 21	1017009/A	SPACER CHAIN GUARD	Unit Price Incl. Tax £0,72

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Royal Enfield. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the REAR SWING ARM AND BEARINGS of your Royal Enfield HIMALAYAN 410 EURO 4 of HIMALAYAN. Let us know if you have any questions.
