GEARBOX FOR ROYAL ENFIELD HIMALAYAN 410 EURO 4

FUEL INJECTION AND SENSORS

(1) 574257/C

W ASHER - 17 X 28 X 1, DRIVE SHAFT THRUST

(10) 574251/B

WASHER THRUST WASHER LOCK

(11) 574250/C

WASHER, 3RD & 4TH DRIVEN GEAR THRUST

(12) 574247/E

GEAR, 3RD DRIVEN

(13) 574246/F

W HEEL, SLIDING DOG

(14) 574245/A

BUSH, 2ND DRIVEN GEAR

(15) 574244/F

GEAR, 2ND DRIVEN

(16) 574241/A

SHAFT COMP, DRIVE

(17) 574238/E

GEAR, 2ND DRIVEN

(18) 574237/E

GEAR, 3RD & 4TH DRIVE

(19) 574235/B

W ASHER - 25 X 34 X 1, 5TH DRIVE GEAR THRUST

(2) 574255/A

BUSH, 1ST DRIVEN GEAR

(20) 574233/E

GEAR, 5TH DRIVE

(21) 574234/A

BUSH, 5TH DRIVE GEAR

(22) 574615/B

SHAFT COMP, COUNTER

(23) 574272/C

SPACER PRIMARY DRIVE

(24) 574226/F

FORK, GEAR SHIFT NO.1

(25) 574225/B

SHAFT, GEAR SHIFT FORK

(26) 574227/F

FORK, GEAR SHIFT NO.2

(27) 574228/F

FORK, GEAR SHIFT NO.3

(28) 574221/D

CAM COMP, GEAR SHIFT

(29) 574223/C

STAR INDEX, GEAR SHIFT CAM

(3) 574614/B

GEAR, 1ST DRIVEN

(30) 574224/C

STEPPED BOLT HEX SOC. HD , STAR INDEX

(31) 574076/C

BOLT STEPPED, GEAR SHIFT CAM STOPPER

(32) 574071/B

ARM STOPPER COMP, GEAR SHIFT CAM

(33) 574022/B

WASHER - 6 X 18 X 1, TENSIONER BOLT

(34) 574075/C

SPRING, GEAR SHIFT CAM STOPPER

(35) 574215/B

CIRCLIP-14 X 1, GEAR SHIFT SHAFT

(36) 574219/C

WASHER 14 X 25 X 0.8, GEAR SHIFT SHAFT THRUST

(37) 574214/C

SHIM, GEAR SHIFT SHAFT

(38) 574216/C

SPRING, GEAR SHIFT SHAFT RETURN

(39) 574210/B

SHAFT COMP, GEAR SHIFT

(4) 574256/B

W ASHER - 20 X 30 X 1, 1ST DRIVEN GEAR THRUST

(40) 574217/B

PLATE, GEAR SHIFT CAM DRIVE

(41) 574218/B

SPRING, GEAR SHIFT CAM DRIVE PLATE

(5) 574253/G

GEAR, 5TH DRIVEN

(6) 574236/B

CIRCLIP 25 X 1.2, 5TH DRIVE GEAR

(7) 574249/B

WASHER, 3RD & 4TH DRIVEN GEAR

(8) 574248/B

BUSH, 3RD & 4TH DRIVEN GEAR

(9) 574252/E

GEAR, 4TH DRIVEN

(A1) 888468

GEARS THRUST W ASHERS BUSH & CIRCLIPS KIT

(A2) 888469

STAR INDEX & STOPPER KIT

	Part number	Description	Qty
# A1	888468	GEARS THRUST W ASHERS BUSH & CIRCLIPS KIT	Not available	£0,00
# A2	888469	STAR INDEX & STOPPER KIT	Not available	£0,00
# 1	574257/C	W ASHER - 17 X 28 X 1, DRIVE SHAFT THRUST	Unit Price Incl. Tax £0,53
# 2	574255/A	BUSH, 1ST DRIVEN GEAR	Unit Price Incl. Tax £3,86
# 3	574614/B	GEAR, 1ST DRIVEN	Unit Price Incl. Tax £24,47
# 4	574256/B	W ASHER - 20 X 30 X 1, 1ST DRIVEN GEAR THRUST	Unit Price Incl. Tax £0,64
# 5	574253/G	GEAR, 5TH DRIVEN	Unit Price Incl. Tax £30,82
# 6	574236/B	CIRCLIP 25 X 1.2, 5TH DRIVE GEAR	Unit Price Incl. Tax £0,50
# 7	574249/B	WASHER, 3RD & 4TH DRIVEN GEAR	Unit Price Incl. Tax £0,50
# 8	574248/B	BUSH, 3RD & 4TH DRIVEN GEAR	Unit Price Incl. Tax £6,65
# 9	574252/E	GEAR, 4TH DRIVEN	Unit Price Incl. Tax £22,67
# 10	574251/B	WASHER THRUST WASHER LOCK	Unit Price Incl. Tax £0,67
# 11	574250/C	WASHER, 3RD & 4TH DRIVEN GEAR THRUST	Unit Price Incl. Tax £1,01
# 12	574247/E	GEAR, 3RD DRIVEN	Unit Price Incl. Tax £22,64
# 13	574246/F	W HEEL, SLIDING DOG	Unit Price Incl. Tax £27,91
# 14	574245/A	BUSH, 2ND DRIVEN GEAR	Unit Price Incl. Tax £7,70
# 15	574244/F	GEAR, 2ND DRIVEN	Unit Price Incl. Tax £19,09
# 16	574241/A	SHAFT COMP, DRIVE	Not available	£0,00
# 17	574238/E	GEAR, 2ND DRIVEN	Unit Price Incl. Tax £19,69
# 18	574237/E	GEAR, 3RD & 4TH DRIVE	Unit Price Incl. Tax £31,31
# 19	574235/B	W ASHER - 25 X 34 X 1, 5TH DRIVE GEAR THRUST	Unit Price Incl. Tax £0,73
# 20	574233/E	GEAR, 5TH DRIVE	Unit Price Incl. Tax £23,72
# 21	574234/A	BUSH, 5TH DRIVE GEAR	Unit Price Incl. Tax £5,24
# 22	574615/B	SHAFT COMP, COUNTER	Unit Price Incl. Tax £66,92
# 23	574272/C	SPACER PRIMARY DRIVE	Unit Price Incl. Tax £13,24
# 24	574226/F	FORK, GEAR SHIFT NO.1	Unit Price Incl. Tax £17,11
# 25	574225/B	SHAFT, GEAR SHIFT FORK	Unit Price Incl. Tax £6,61
# 26	574227/F	FORK, GEAR SHIFT NO.2	Unit Price Incl. Tax £16,38
# 27	574228/F	FORK, GEAR SHIFT NO.3	Unit Price Incl. Tax £17,46
# 28	574221/D	CAM COMP, GEAR SHIFT	Unit Price Incl. Tax £24,78
# 29	574223/C	STAR INDEX, GEAR SHIFT CAM	Unit Price Incl. Tax £12,98
# 30	574224/C	STEPPED BOLT HEX SOC. HD , STAR INDEX	Unit Price Incl. Tax £3,11
# 31	574076/C	BOLT STEPPED, GEAR SHIFT CAM STOPPER	Not available	£0,00
# 32	574071/B	ARM STOPPER COMP, GEAR SHIFT CAM	Unit Price Incl. Tax £4,93
# 33	574022/B	WASHER - 6 X 18 X 1, TENSIONER BOLT	Unit Price Incl. Tax £0,25
# 34	574075/C	SPRING, GEAR SHIFT CAM STOPPER	Unit Price Incl. Tax £0,73
# 35	574215/B	CIRCLIP-14 X 1, GEAR SHIFT SHAFT	Unit Price Incl. Tax £0,25
# 36	574219/C	WASHER 14 X 25 X 0.8, GEAR SHIFT SHAFT THRUST	Unit Price Incl. Tax £0,25
# 37	574214/C	SHIM, GEAR SHIFT SHAFT	Unit Price Incl. Tax £0,53
# 38	574216/C	SPRING, GEAR SHIFT SHAFT RETURN	Unit Price Incl. Tax £1,64
# 39	574210/B	SHAFT COMP, GEAR SHIFT	Unit Price Incl. Tax £19,09
# 40	574217/B	PLATE, GEAR SHIFT CAM DRIVE	Unit Price Incl. Tax £9,98
# 41	574218/B	SPRING, GEAR SHIFT CAM DRIVE PLATE	Unit Price Incl. Tax £0,48

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Royal Enfield. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the GEARBOX of your Royal Enfield HIMALAYAN 410 EURO 4 of HIMALAYAN. Let us know if you have any questions.
